Seamless Transition: Converting Oracle 19c Non-CDB to Pluggable Database (PDB)

Here’s an exercise of the steps involved in converting a 19c Non-CDB database to a Pluggable Database (PDB).

1. Preparing the Non-CDB: Read-Only Mode

This initial phase secures the non-CDB in a static condition. By opening it for read-only access, you freeze its state, making it stable for the upcoming conversion process.SQL

SQL> select name from v$database;

NAME
---------
NONCDB

SQL

SQL> shutdown immediate;

Database closed.
Database dismounted.
ORACLE instance shut down.

SQL

SQL> startup open read only

ORACLE instance started.

Total System Global Area 1.8119E+10 bytes
Fixed Size                  7641528 bytes
Variable Size            1.0133E+10 bytes
Database Buffers         7851737088 bytes
Redo Buffers              126574592 bytes
Database mounted
Database opened.

SQL

SQL> select name,open_mode from v$database;

NAME       OPEN_MODE
---------  --------------------
NONCDB     READ ONLY

2. Crafting the PDB Description

This step involves generating a detailed blueprint of your non-CDB. This blueprint, saved as an XML file, contains all the necessary structural information for the target Container Database (CDB) to understand and incorporate it as a Pluggable Database (PDB).SQL

BEGIN
  DBMS_PDB.DESCRIBE(pdb_descr_file => '/export/home/oracle/NonCDB.xml');
END;
/

PL/SQL procedure successfully completed.

3. Deactivating the Non-CDB

Once the blueprint is complete, the non-CDB is fully shut down. This action releases all resources and prepares the database’s files to be disconnected from their current instance, making them available for the plugging operation into the CDB.SQL

SQL> shutdown immediate;

Database closed.
Database dismounted.
ORACLE instance shut down.
SQL> exit

NOW IN CDB

The following actions take place within your Container Database (CDB).

4. Verifying Compatibility with the CDB

Before the actual plugging, this step checks if the non-CDB’s blueprint aligns with the CDB’s environment. This validation process helps identify any potential conflicts or adjustments needed, ensuring a smoother integration.SQL

SET SERVEROUTPUT ON;
DECLARE
  compatible CONSTANT VARCHAR2(3) := CASE DBMS_PDB.CHECK_PLUG_COMPATIBILITY(pdb_descr_file => '/export/home/oracle/NonCDB.xml')
  WHEN TRUE THEN 'YES'
  ELSE 'NO'
  END;
BEGIN
  DBMS_OUTPUT.PUT_LINE(compatible);
END;
/

YES

PL/SQL procedure successfully completed.

5. Reviewing Post-Plug-in Discrepancies (Example Output)

After the non-CDB is plugged in (which typically involves a CREATE PLUGGABLE DATABASE ... USING ... command not shown here), this final step examines any reported issues or required follow-up actions. This view details warnings about necessary scripts to run or parameter mismatches that need attention.SQL

select name,cause,type,message,status from PDB_PLUG_IN_VIOLATIONS where name='NONCDB';

NAME                 CAUSE                TYPE
-------------------- -------------------- ---------
MESSAGE                                  STATUS
-----------------------------------      ---------
NONCDB               Non-CDB to PDB       WARNING
PDB plugged in is a non-CDB,             PENDING
requires noncdb_to_pdb.sql be run.

NONCDB               Parameter            WARNING
CDB parameter memory_target              PENDING
mismatch: Previous 17280M Current
13856M

• Non-CDB to PDB WARNING: This indicates that an internal script must be executed within the newly plugged-in PDB to complete its transformation and integration into the CDB framework.
• Parameter WARNING: This highlights a difference in a key memory setting between the former non-CDB’s configuration and the CDB’s current configuration. This may require manual review and adjustment to ensure optimal performance within the new architecture.
